| Items | Ratings | Remarks |
|---|---|---|
| Rated zero-power resistance R0°C | 1000 Ω | Zero-power resistance is measured at 0°C |
| Tolerance of rated zero-power resistance R0°C | ±0.59 Ω | Does not include line resistance |
| Hi-pot test | AC1800V / 2 Sec | Shall withstand between each end of the sensor and the shell |
| Thermal time constant | About 25~30 Sec | |
| Dissipation constant | Min 3mW/°C | |
| Operating temperature range | -40°C ~ +200°C |
